JWDS-1836 KIT - MACHINE AND STAND

JWDS-1836 KIT - MACHINE AND STAND

AB723530K
$1,799.99

JWDS-1836 KIT - MACHINE AND STAND

Introducing the newly designed JET JWDS-1836 Drum Sander from JET. The 1.75 horsepower motor delivers plenty of power to handle just about any sanding task. The innovative tool-less parallelism system keeps adjustments simple. The worktable is easily positioned by a turn of the parallelism dial. The variable-speed rate permits you to choose the optimal feed rate for a full range of projects, while the Sandsmart feature continuously monitors the load on the drum motor to prevent an overload situation. The mirrored design of the dust hood optimizes dust collection preventing chips and dust from getting between your work-piece and the finish. The JWDS-1836 Drum Sander delivers everything you need for an effortless finish.

JWDS-1836 Drum Sander with Stand

Features & Benefits

  • Self-Cooling Drum
  • Drum is easily removable
  • Drum utilizes sealed and permanently lubricated ball bearings for longer life
  • Infinitely variable speed control of up to 10 feet per minute allows the user to choose the optimal feed rate
  • Integrated on/off switch and variable speed control knob are conveniently located
  • Precision-flattened reinforced steel conveyor bed
  • Precision-machined and dynamically balanced extruded aluminum drum is designed to dissipate heat and protect the work surface from heat-damage
  • Separate feed and drum motors provide independent control, optimizing the performance of the sander
  • Stand features a 20" x 37" footprint to increase stability and has a storage shelf and pre-drilled holes for casters
  • The relative depth scale on the handwheel allows the user to reset and measure the depth for every project
SAP EAN Number Code (UPC) 731325525229
Model Number JWDS-1836
SAP Base Unit of Measure EA
SAP Commodity Code 8465.93.0075
SAP Country of Origin Taiwan
Warranty 5 Year
SAP Delivery Plant JNA
SAP Length 39
SAP Unit of Dimension IN
SAP Height 25
SAP Unit of Dimension IN
SAP Width 22.5
SAP Unit of Dimension IN
SAP Gross Weight 190
SAP Weight Unit LBS
SAP Net weight 164
SAP Weight Unit LBS
SAP Transportation Group LTL
Accessories Products 60-18036,60-18060,60-18080,60-18100,60-18120,60-18150,60-18180,60-18220,60-9036,60-9060,60-9080,60-9100,60-9120,60-9150,60-9180,60-9220,723521,98-0130
Drum Bearing Diameter (In.) 1
Drum Diameter (In.) 5
Dust Collection Minimum CFM Required (CFM) 500
Dust Port Outside Diameter (In.) 4
End User Sellable No
Item Display Order 20.0000
Maximum Board Thickness (In.) 3
Microsite URL http://www.jettools.com/us/en/new-products-and-offers/new-products/16-32-drum-sander/
Minimum Board Length (In.) 2-3/8
Minimum Board Thickness (In.) 1/32
Motor Amps 15
Motor Power (HP) 1-3/4
Number of Sanding Drums 1
Prop 65 Cancer and Reproductive Harm
Recommended Circuit Size (Amps.) 20
Weight (Lbs.) 164.0000
Weight (Lbs.) (Unit) Pound
AB723530K

Data sheet

Package Type
BOX
Default Qty
1
