540A Series Carriage C-Clamps are ideal for light industrial, woodworking and repair applications. They feature a black oxide coating, oscillating head, and sliding cross pin handle.
540A Series C-Clamp 0 - 4 Opening Capacity
Features & Benefits
- Frames made from high strength ductile iron castings
- Sliding pin (vise type) handle, single acme thread rolled spindle and oscillating ball and socket tip
- Wilton's heaviest-duty carriage clamp available
| SAP EAN Number Code (UPC) | 19907220039 |
| Model Number | 540A-4 |
| SAP Base Unit of Measure | EA |
| SAP Commodity Code | 8205.70.0090 |
| SAP Country of Origin | China |
| Warranty | Lifetime |
| SAP Delivery Plant | JNA |
| SAP Length | 8.8 |
| SAP Unit of Dimension | IN |
| SAP Height | 1.4 |
| SAP Unit of Dimension | IN |
| SAP Width | 4.5 |
| SAP Unit of Dimension | IN |
| SAP Gross Weight | 2.1 |
| SAP Weight Unit | LBS |
| SAP Net weight | 2.1 |
| SAP Weight Unit | LBS |
| SAP Transportation Group | Parcel |
| Clamping Force (lbs) | 2,150 |
| End User Sellable | No |
| Item Display Order | 30.0000 |
| Opening Capacity Max (In.) | 0 -- 4 |
| Prop 65 | Cancer and Reproductive Harm |
| Spindle Diameter (In.) | 5/8 |
| Throat Depth (In.) | 2-1/16 |
