JBOS-5 BENCH OSCILLATING SNDR(TEXT)

JBOS-5 BENCH OSCILLATING SNDR(TEXT)

AB708404
$699.99

JBOS-5 BENCH OSCILLATING SNDR(TEXT)

The JBOS-5 Benchtop Spindle Sander has a powerful 1/2HP induction motor and a large 14-1/2 table that tilts to 45 which easily handles the toughest sanding projects. A heavy-duty worm gear system provides one-inch oscillating action, which prolongs sleeve life and helps prevent burnishing of the workpiece. Four inserts are provided, and 5 spindles with sanding sleeves.

JBOS-5, Benchtop Oscillating Spindle Sander, 1/2HP, 1Ph 115V

Features & Benefits

  • 1" Oscillating action reduces friction heat to protect wood and prolong sleeve life
  • Built-in storage racks keep spindles and table inserts handy
  • Four table inserts are provided (3/4" and 1" Oblong, 3/4" and 1" Round), to prevent dust and debris from falling into the motor and help protect operator
  • Includes 1/4", 1/2", 5/8", 1-1/2", 2" spindle assemblies with 100 grit paper
  • Includes four non-skid rubber feet keep machine stable during use
  • Main spindle support runs on precision ball bearings and is oscillated by a heavy-duty worm and gear mechanism for consistent performance
  • Oscillation gears run in a sealed lubricated box to prolong their life and durability
  • Spindles have threaded ends for quick, easy changes
SAP EAN Number Code (UPC) 662755211492
Model Number JBOS-5
SAP Base Unit of Measure EA
SAP Commodity Code 8465.93.0075
SAP Country of Origin Taiwan
Warranty 5 Year
SAP Delivery Plant JNA
SAP Unit of Dimension IN
SAP Unit of Dimension IN
SAP Unit of Dimension IN
SAP Gross Weight 75.6
SAP Weight Unit LBS
SAP Net weight 75.6
SAP Weight Unit LBS
SAP Transportation Group LTL
Accessories Products 575891,575893,575894,575901,575903,575904,575906,575908,575909,575921,575923,575924,575931,575933,575934,575941,575943,575944,709534,709539,JW1000
Dust Port Outside Diameter (In.) 2
End User Sellable No
Item Display Order 10.0000
Motor Amps 3
Motor Phase 1
Motor Power (HP) 1/2
Oscillations Per Minute 30
Oscillation Stroke (In.) 1
Prop 65 Cancer and Reproductive Harm
Spindle Speed (RPM) 1,725
Style (Type) Benchtop
Table Size (L x W) (In.) 14-1/2 x 14-1/2
AB708404

Data sheet

Package Type
BOX
Default Qty
1
