The JBOS-5 Benchtop Spindle Sander has a powerful 1/2HP induction motor and a large 14-1/2 table that tilts to 45 which easily handles the toughest sanding projects. A heavy-duty worm gear system provides one-inch oscillating action, which prolongs sleeve life and helps prevent burnishing of the workpiece. Four inserts are provided, and 5 spindles with sanding sleeves.
JBOS-5, Benchtop Oscillating Spindle Sander, 1/2HP, 1Ph 115V
Features & Benefits
- 1" Oscillating action reduces friction heat to protect wood and prolong sleeve life
- Built-in storage racks keep spindles and table inserts handy
- Four table inserts are provided (3/4" and 1" Oblong, 3/4" and 1" Round), to prevent dust and debris from falling into the motor and help protect operator
- Includes 1/4", 1/2", 5/8", 1-1/2", 2" spindle assemblies with 100 grit paper
- Includes four non-skid rubber feet keep machine stable during use
- Main spindle support runs on precision ball bearings and is oscillated by a heavy-duty worm and gear mechanism for consistent performance
- Oscillation gears run in a sealed lubricated box to prolong their life and durability
- Spindles have threaded ends for quick, easy changes
| SAP EAN Number Code (UPC) | 662755211492 |
| Model Number | JBOS-5 |
| SAP Base Unit of Measure | EA |
| SAP Commodity Code | 8465.93.0075 |
| SAP Country of Origin | Taiwan |
| Warranty | 5 Year |
| SAP Delivery Plant | JNA |
| SAP Unit of Dimension | IN |
| SAP Unit of Dimension | IN |
| SAP Unit of Dimension | IN |
| SAP Gross Weight | 75.6 |
| SAP Weight Unit | LBS |
| SAP Net weight | 75.6 |
| SAP Weight Unit | LBS |
| SAP Transportation Group | LTL |
| Accessories Products | 575891,575893,575894,575901,575903,575904,575906,575908,575909,575921,575923,575924,575931,575933,575934,575941,575943,575944,709534,709539,JW1000 |
| Dust Port Outside Diameter (In.) | 2 |
| End User Sellable | No |
| Item Display Order | 10.0000 |
| Motor Amps | 3 |
| Motor Phase | 1 |
| Motor Power (HP) | 1/2 |
| Oscillations Per Minute | 30 |
| Oscillation Stroke (In.) | 1 |
| Prop 65 | Cancer and Reproductive Harm |
| Spindle Speed (RPM) | 1,725 |
| Style (Type) | Benchtop |
| Table Size (L x W) (In.) | 14-1/2 x 14-1/2 |
