DROP FORGED C-CLAMP H412(TEXT)

DROP FORGED C-CLAMP H412(TEXT)

AB20307
$185.99

DROP FORGED C-CLAMP H412(TEXT)

Columbian Economy C-clamps feature drop forged frames and an oscillating head that provides a tighter hold on angular work pieces.

Wilton Columbian Economy Drop Forged C-Clamp 0 - 12 Opening Capacity, 5-3/4" Throat Depth

Features & Benefits

  • Drop forged, regular duty with extra deep throat
  • Exceptional value and performance
  • Improved frame design allows for a higher proof test, greater throat depth, and lower overall weight
  • V grooved anvil allows secure holding of all materials including rounds, squares and flats.
SAP EAN Number Code (UPC) 19907203070
Model Number H412
SAP Base Unit of Measure EA
SAP Commodity Code 8205.70.0090
SAP Country of Origin China
Warranty Lifetime
SAP Delivery Plant JNA
SAP Length 20.5
SAP Unit of Dimension IN
SAP Height 2.2
SAP Unit of Dimension IN
SAP Width 10.2
SAP Unit of Dimension IN
SAP Gross Weight 14.35
SAP Weight Unit LBS
SAP Net weight 14.35
SAP Weight Unit LBS
SAP Transportation Group Parcel
Clamping Force (lbs) 9,300
End User Sellable No
Item Display Order 70.0000
Opening Capacity Max (In.) 0 -- 12
Prop 65 Cancer and Reproductive Harm
Spindle Diameter (In.) 7/8
Throat Depth (In.) 5-3/4
AB20307

Data sheet

Package Type
BOX
Default Qty
1
