JWSS-22B - SCROLL SAW BASE MACH W/SWITC

JWSS-22B - SCROLL SAW BASE MACH W/SWITCH

AB727200B
$1,049.99

JWSS-22B - SCROLL SAW BASE MACH W/SWITCH

Say hello to JET's 22" Scroll Saw. Combining best-in-class features with innovation and thoughtful design to create the machine you've been waiting for. The best part about this saw is the blade change process. Our exclusive upper mechanism clamps and tensions the blade in one step. In addition to the upper mechanism, the toolless lower blade holder is removable and the table features a slot for the blade. The features don't stop there: this saw offers twenty-two inches of throat capacity and an arm that tilts forty degrees left and forty five degrees right, keeping the worktable flat for more accurate cutting. This saw is designed to optimize your scrolling experience. From the variable speed range to a top lift, spring loaded arm it comes fully loaded with all the features youd expect.

JWSS-22B 22" Scroll Saw with Foot Switch

Features & Benefits

  • Conveniently located speed and tension controls
  • Included Equipment: Material hold down, Onboard Dust Blower, Foot Switch
  • Integrated blade storage features slots for pre-loaded blades and a built-in wrench for changing blades
  • Large 12-7/8 x 23 cast iron table provides a stable working surface while also limiting vibration
  • Removable dust port on underside of table to collect dust at the source
  • Top lift, spring loaded arm raises 10 and stays up until pulled back down
  • Variable speed range of 400 1550 strokes per minute
SAP EAN Number Code (UPC) 731325456417
Model Number JWSS-22B
SAP Base Unit of Measure EA
SAP Commodity Code 8465.91.0049
SAP Country of Origin Taiwan
Warranty 5 Year
SAP Delivery Plant JNA
SAP Length 39.4
SAP Unit of Dimension IN
SAP Height 23.6
SAP Unit of Dimension IN
SAP Width 21.6
SAP Unit of Dimension IN
SAP Gross Weight 90
SAP Weight Unit LBS
SAP Net weight 68.2
SAP Weight Unit LBS
SAP Transportation Group Parcel
Accessories Products 727200S,727201,JWSS22B-253,JWSS22B-335
Assembled Machine Dimensions (L x W x H) (In.) (English United States, Ecommerce) 33 x 15-1/2 x 17-1/2
Easy2 URL http://content.jettools.com/assets/3D/scroll_vr.52.html
End User Sellable No
Item Display Order 3.0000
Maximum Cutting Depth (In.) 2
Motor Amps 1.3
Net Weight (Lbs.) 68.2000
Net Weight (Lbs.) (Unit) Pound
Prop 65 Cancer and Reproductive Harm
Stroke Length (In.) 3/4
Table Height (In.) 7-3/4 to 8-3/4
Table Material Cast Iron
Table Size (L x W) (In.) 12-2/3 x 23-5/8
Tilting Function Arm
AB727200B

Data sheet

Package Type
BOX
Default Qty
1
