ProShop II, 115V, 52" Rip, Cast Wings

ProShop II, 115V, 52" Rip, Cast Wings

AB725001K
$2,349.99

ProShop II, 115V, 52" Rip, Cast Wings

The JET ProShop Table Saw offers features you expect from a high-end cabinet saw, in the compact design of a contractor-style machine. The redesigned transparent blade guard has independent leaves, and the quick release riving knife reduces chance of kickback. A low profile riving knife is included for non-through cuts. The exclusive ProShop fence system is available in 30 or 52 rip capacity.

The JPS-10 1.75 HP 115V 52" Proshop Tablesaw with Cast wings

Features & Benefits

  • Convenient, magnetic paddle switch for the safest operation possible
  • CSA Certified
  • Improved dust shroud around blade for greater dust collection
  • Innovative single belt design for easier belt tensioning and reduced vibration
  • Low profile riving knife included
  • Motor reset switch conveniently relocated to the power switch, instead of the motor
  • Newly designed arbor lock to change blades quickly and easily
  • On board storage for all included accessories
  • Quick release riving knife for hassle free riving knife changes
  • Redesigned guard for better protection and ease of use
SAP EAN Number Code (UPC) 731325727494
Model Number JPS-10
SAP Base Unit of Measure EA
SAP Commodity Code 8465.91.0078
SAP Country of Origin Taiwan
Warranty 5 Year
SAP Delivery Plant JNA
SAP Length 82
SAP Unit of Dimension IN
SAP Height 43
SAP Unit of Dimension IN
SAP Width 40
SAP Unit of Dimension IN
SAP Gross Weight 352.45
SAP Weight Unit LBS
SAP Net weight 325.95
SAP Weight Unit LBS
SAP Transportation Group Parcel
Accessories Products 708118,708158,709209,725004
Arbor Speed (RPM) 4000
Blade Diameter (In.) 10
Dust Collection Minimum CFM Required (CFM) 350
Dust Port Outside Diameter (In.) 4
End User Sellable No
Item Display Order 10.0000
Maximum Depth of Cut at 45 Degrees (In.) 2-1/8
Maximum Depth of Cut (In.) 3-1/8
Maximum Diameter of Dado (In.) 8
Maximum Rip Left of Blade (In.) 13-1/2
Maximum Rip Right of Blade (In.) 52
Maximum Width of Dado (In.) 13/16
Miter Gauge Type T-Slot with Stops
Motor Amps 7.4
Motor Power (HP) 1-3/4
Motor Voltage (V.) 115
Prewired Voltage (V.) 115
Prop 65 Cancer and Reproductive Harm
Recommended Circuit Size (Amps.) 10
Style (Type) Contractor
Table Height from Floor (In.) 34-3/4
Table in Front of Saw Blade at Maximum Depth of Cut (In.) 8.81
Table Size (L x W) (In.) 20 x 27
Table Type Cast Iron
AB725001K

Data sheet

Package Type
BOX
Default Qty
1
