JDP-17 17" DRILL PRESS, 3/4HP

JDP-17 17" DRILL PRESS, 3/4HP

AB716300
$2,029.99

JDP-17 17" DRILL PRESS, 3/4HP

Introducing the new JET JDP-17, 17 Drill Press. From a full 5 of spindle travel to the sturdy cast iron head with a poly v-belt drive system, this drill press is designed to perform. This drill press also features a long-lasting, built-in LED work light to provide direct lighting while reducing shadows. A large 14" x 19" work table provides plenty of support with an edge designed for easy clamping. CSA Certified.

17" Drill Press

Features & Benefits

  • Integrated depth stop makes repetitive drilling quick and easy
  • Large cast iron base provides stability
  • One-handed belt tensioning allows for rapid speed changes
  • Power switch features a safety key and large, paddle-style off button
  • Powered by an efficient 3/4HP, 1Ph, 115V TEFC motor and poly-v belt drive system
  • Replaceable MDF table insert
  • Table edge lip designed to make clamping easy
  • Xacta-X laser system easily identifies the drill center
SAP EAN Number Code (UPC) 731325340013
Model Number JDP-17
SAP Base Unit of Measure EA
SAP Commodity Code 8465.95.0055
SAP Country of Origin China
Warranty 5 Year
SAP Delivery Plant JNA
SAP Unit of Dimension IN
SAP Unit of Dimension IN
SAP Unit of Dimension IN
SAP Gross Weight 224
SAP Weight Unit LBS
SAP Net weight 186
SAP Weight Unit LBS
SAP Transportation Group LTL
Assembled Machine Dimensions (L x W x H) (In.) (English United States, Ecommerce) 28-1/2 x 19 x 65
Chuck Distance to Base (In.) 42-7/8
Chuck Distance to Table (In.) 25-7/8
Chuck Size (In.) 5/8
Column Diameter (In.) 3-5/32
End User Sellable No
Item Display Order 50.0000
Motor Power (HP) 3/4
Number of Spindle Speeds 16
Prop 65 Cancer and Reproductive Harm
Recommended Circuit Size (Amps.) 15
Spindle Distance to Base (In.) 46-1/2
Spindle Distance to Table (Max.) (In.) 30
Spindle Travel (In.) 5
Style (Type) Floorstanding Model
Swing (In.) 16-7/8
Table Size (L x W) (In.) 14 x 19
Weight (Lbs.) 187.0000
Weight (Lbs.) (Unit) Pound
AB716300

Data sheet

Package Type
BOX
Default Qty
1
